Filtration of sugar syrup

Filtration of sugar syrup is used to remove mechanical impurities, clarify and sterilizing.

Contact our specialist
Features and applications
Recommendations for filter cartridges

Features and applications

The system for filtration of sugar syrup usually consists of a filter holder DS type or UPF filtration system  with a set of filter cartridges.

Depending on the required degree of filtration, the system can include several stages of purification (up to obtaining a sterile syrup using membrane cartridge filtration).

Recommendations for filter cartridges

Filter cartridges for removal of mechanical impurities

NPP Technofilter presents a filter cartridge EPNS made of stainless mesh with the possibility of multiple flushing and regeneration.

CHARACTERISTICS

ADVANTAGES

100% chemically resistant filter with excellent performance.

  • Wide chemical compatibility (pH 1-14).
  • Excellent thermal resistance (up to 200 °C, full-metal).
  • Longer service life due to increased surface area (pleated).
  • Available with a wide range of rating from 5 to 100 microns.

Reinforced construction

  • Reliable integrity of filter cartridge in harsh environments
  • Withstands steam sterilization in line, multiple backwash rinses and all types of sanitation treatment

Filter housing of the DS type for liquid filtration

NPP Technofilter presents a series of filter housings of the DS type are made of stainless steel AISI 304 and AISI 316L.

The filter holder type (height and number of filter cartridges) is selected depending on the filtration.

Distinctive features of DS-1, DS-5, DS-8 filter holders

  • High quality polishing of external and internal surfaces.
  • Availability of internal arias for inspection and washing.
  • The absence of hidden and hard-to-reach spaces due to an additional separator.
  • Lack of dead zone.
  • Complete emptying of the liquid through drain valves.
  • High tightness of the media interfaces (initial medium / filtrate / external medium) due to the accuracy and cleanliness of mounting bores for adapters and surfaces for sealing elements
  • Simplified assembly at site due to swiveling connection of nozzles and base. Pressure gauges to control hydraulic resistance are supplied.

Technical and operational characteristics of filter housings

Name

Number of filters × height (mm)

Dimensions, mm

Max. operating pressure, MPa

DN, mm

Adapter

DS-5-А(D)-500P

5х500

475х270х1040

0.6

40

44,5/56

DS -5-А(D)-750P

5х750

475х270х1290

0.6

40

44,5/56

DS -5-А(D)-1000P

5х1000

475х270х1540

0.6

40

44,5/56

DS -8-А(D)-500P

8х500

640х395х1145

0.6

50

44,5/56

DS-8-А(D)-750P

8х750

640х395х1395

0.6

50

44,5/56

DS-8-А(D)-1000P

8х1000

640х395х1645

0.6

50

44,5/56

DS-18-А-500P

18х500

789х490х1119

0.6

80

44,5

DS-18-А-750P

18х750

789х490х1369

0.6

80

44,5

DS-18-А-1000P

18х1000

789х490х1619

0.6

80

44,5

DS-24-А-1000P

24х1000

667х592х1714

0.6

80

44,5

DS-29-А-1000P

29х1000

667х592х1714

0.6

80

44,5
