The trap filtration of beer after the kieselguhr filter is a system that allows not to use a filter presses. In this system, filtration is carried out in a closed case with minimal loss of carbon dioxide without the contact of beer with air, preserving the taste of the drink. At the same time, product losses and labor intensity of the process are significantly reduced.
Benefits
Trap filtration is widely used in the EU countries and in Russia (including large beer corporations). It allows to significantly reduce the cost of consumables (in comparison with the filter carton) and the costs due to product losses.
The trap filtration system consists of a filter holder (see below) with a set of filter cartridges.
Recommendations for filter cartridges
Filters for efficient and economical trap filtration of beer
NPP Technofilter presents a cartridge filter EPVg.P for high-quality trap filtration of beer with the possibility of multiple washing and regeneration.
|
CHARACTERISTICS |
ADVANTAGES |
|---|---|
|
100% full polypropylene filter cartridge with excellent performance and high chemical resistance. |
|
|
High efficiency of microparticle retention (98-99.5%) |
|
|
Reinforced structure, stable matrix |
|
|
Non-toxic |
|
Operational characteristics
- The maximum pressure drop - 0.5 MPa at 20 °C, 0.25 MPa at 80 °C
- Rinsing with hot water (at least 100 cycles) – 90 °C, 30 min
- Steam sterilization (at least 20 cycles) - up to 135 °C, 30 min
Filter housing of the DS type for liquid filtration
NPP Technofilter presents a series of filter holders of the DS type are made of stainless steel AISI 304 and AISI 316L.
The filter holder type (height and number of filter cartridges) is selected depending on the filtration.
Distinctive features of DS-1, DS-5, DS-8 filter holders
- High quality polishing of external and internal surfaces.
- Availability of internal arias for inspection and washing.
- The absence of hidden and hard-to-reach spaces due to an additional separator.
- Absence of dead space.
- Complete emptying of the liquid through drain valves.
- High tightness of the media interfaces (initial medium / filtrate / external medium) due to the accuracy and cleanliness of machining the seet places for adapters and surfaces for sealing elements
- Simplified on-site installation due to swiveling connection of nozzles and base. Pressure gauges to control hydraulic resistance are supplied.
Technical and operational characteristics of filter holders
|
Name |
Number of filters and height (mm) |
Dimensions, mm |
Max. operating pressure, MPa |
DN, mm |
Adapter |
|---|---|---|---|---|---|
|
DS-5-А(D)-500P |
5х500 |
475х270х1040 |
0.6 |
40 |
44,5/56 |
|
DS -5-А(D)-750P |
5х750 |
475х270х1290 |
0.6 |
40 |
44,5/56 |
|
DS -5-А(D)-1000P |
5х1000 |
475х270х1540 |
0.6 |
40 |
44,5/56 |
|
DS -8-А(D)-500P |
8х500 |
640х395х1145 |
0.6 |
50 |
44,5/56 |
|
DS-8-А(D)-750P |
8х750 |
640х395х1395 |
0.6 |
50 |
44,5/56 |
|
DS-8-А(D)-1000P |
8х1000 |
640х395х1645 |
0.6 |
50 |
44,5/56 |
|
DS-18-А-500P |
18х500 |
789х490х1119 |
0.6 |
80 |
44,5 |
|
DS-18-А-750P |
18х750 |
789х490х1369 |
0.6 |
80 |
44,5 |
|
DS-18-А-1000P |
18х1000 |
789х490х1619 |
0.6 |
80 |
44,5 |
|
DS-24-А-1000P |
24х1000 |
667х592х1714 |
0.6 |
80 |
44,5 |
|
DS-29-А-1000P |
29х1000 |
667х592х1714 |
0.6 |
80 |
44,5 |
