Most filling lines use a two-stage wine filtration scheme.
The combination "prefilter - final filter" increases the reliability of the process, ensures maximum efficiency and cost effectiveness of the filtration system.
For high-quality prefiltration, our company recommends pleated multiply regenerated depth filter cartridges of EPV.S, EPV.STs and EPVg.P.
Recommendations for filter cartridges
Specifications
Recommendations for filter cartridges
Recommended options for pre-filtration before membrane filter cartridges
| Final membrane filter | EPM.PS-045 | EPM.PS-065 |
|---|---|---|
| Base protection | EPVg.P-100 or EPV.STs-300/100 | EPVg.P-150 |
| Intensive protection (for cold sterile filling) | EPV.S-050 or EPVg.P-065 | EPV.STs-300/080 or EPVg.P-100 |
Specifications
Brief specification of depth filter cartridges used in the preliminary and final stages of wine filtration
| Brand | Filter medium | Retention efficiency, μm | Properties | Brief description |
|---|---|---|---|---|
| EPV.S | microfiber glass | 0,5 | Pleated, Hydrophilic | Stable rigid matrix, chemically stable in acidic, alkaline and alcoholic media, absolute retention capacity, multiple regeneration, increased contamination capability and lifetime. Operating temperature up to 90 ° С. Can be used as a finishing filter for hot filling. |
| EPV.SC | Fiberglass/ cellulose/ polypropylene | 0,8; 1,0 | Pleated, Hydrophilic | Stable rigid matrix, high retention capacity, increased contamination capability and lifetime |
| EPVg.P | 100% polypropylene chemically resistant | 0,5; 0,65; 0,8; 1,0; 1,5; 2,0; 5,0; 10,0; 20,0 | Pleated, Hydrophilic | Stable rigid matrix, absolute retention capacity, multiple regeneration, increased contamination capability and lifetime. Operating temperature up to 90 ° С. Can be used as an effective pre-filter and as a finishing filter for hot filling and pasteurization. |
