Trap filtration of kvass after the kieselguhr filter is a system that allows not to use a filter presses. Filtration is carried out in a closed housing with minimal loss of carbon dioxide and prevents the contact of kvass with air, preserving the taste of the drink. At the same time, product losses and labor intensity of the process are significantly reduced.
Benefits
Trap filtration of kvass is widely used in the EU countries and in Russia (including large beer corporations). It allows significantly to reduce the cost of consumables (in comparison with the filter carton) and the costs due to product losses.
The trap filtration system consists of a filter holder (see below) with a set of filter cartridges.
Recommendations for filter cartridges
Filters for efficient and economical trap filtration of kvass
NPP Technofilter presents a cartridge filter EPVg.P for high-quality trap filtration of beer with the possibility of multiple washing and regeneration.
|
CHARACTERISTICS |
ADVANTAGES |
|---|---|
|
100% full polypropylene filter cartridge with excellent performance and high chemical resistance. |
|
|
High efficiency of microparticle retention (98-99.5%) |
|
|
Reinforced structure, stable matrix |
|
|
Non-toxic |
|
Operational characteristics:
- The maximum pressure drop - 0.5 MPa at 20 °C, 0.25 MPa at 80 °C
- Rinsing with hot water (at least 100 cycles) – 90 °C, 30 min
- Steam sterilization (at least 20 cycles) - up to 135 °C, 30 min
