DS-P stainless steel filter holders are intended for removal of mechanical particles from water steam in steam supply systems designed for treatment of vessels, set-ups and other equipment.
Configuration
DS-P filter holders are used with all-metal filter elements made of pleated stainless steel mesh EPNS.P.
DS-P filter holders are equipped with condensate collection tray and a drain valve in the bottom of the holder.
Material
12X18H10T (AISI 304) Stainless steel
Технико-эксплутационные характеристики ДС-П для фильтрации пара
|
Brand |
Water flow rate, m³/h |
Max. operating pressure, МPа |
Max. operating temperature, °С |
Filter holder diameter, mm |
Filter holder height, mm |
Weight, kg |
Nominal diameter, mm |
|---|---|---|---|---|---|---|---|
|
DS-P-50 |
50 |
0,8 |
150 |
91 |
277 |
2,3 |
12 |
|
DS-P-250 |
250 |
0,8 |
150 |
130 |
515 |
6,5 |
32 |
|
DS-P-500 |
500 |
0,8 |
150 |
130 |
824 |
7,6 |
50 |
|
DS-P-1500 |
1500 |
1,2 |
150 |
250 |
930 |
29 |
80 |
Ordering information
|
DS |
P |
50 |
|---|---|---|
|
Brand |
For steam |
Steam flow rate, kg/h |
|
|
|
50 |
